RCW-T15.6M 15.6kV MV outdoor vacuum recloser
$5000.00
Model
RCW-T15.6M/1250-25C
RCW-T15.6M/1250-25
RCW-T15.6M/800-20C
RCW-T15.6M/800-20
RCW-T15.6M/630-16C
RCW-T15.6M/630-16
RCW-T15.6M/400-12.5C
RCW-T15.6M/400-12.5
Basic info
Brand ROCKWILL
Model NO. RCW T15.6M MV outdoor vacuum recloser
Rated voltage 15.6kV
Rated normal current 1250A
Rated short circuit breaking current 25kA
Power frequency withstand voltage 65kV/min
Rated lightning impulse voltage 140kV
manual closing Yes
Series RCW
Product Detail

Description:

The RCW   series automatic circuit reclosers can use on overhead distribution lines as well as distribution substation applications for allvoltage classes 11kV up to 38kV at 50/60Hz power system.  and it’s rated current can reach 1250A.The RCW   series automatic circuit reclosers integrates the functions of control, protection, measurement, communication, fault detection, on-line monitoring of closing or opening.The RCW   series vacuum recloser is mainly combined with integration terminal, current transformer, permanent magnetic actuator and it’s recloser controller.

Features:

  • Optional grades available in rated current range.

  • With optional relay protection and logic for user selection.

  • With optional communication protocols and I/O ports for users to choose.

  • PC software for controller testing, setup, programming, updates.

Parameters



External dimensions



Environmental requirement


Product show:

正方型 单相.png


How does an outdoor vacuum recloser work?

  • Normal Operation: The recloser is in the closed position, and the line is supplying power normally. During this time, current flows through the main contacts of the recloser, and the vacuum arc quenching chamber remains in a high-insulation state. The operating mechanism maintains the closed position to ensure stable power transmission.

  • Fault Detection and Tripping: When a fault such as a short circuit or overload occurs in the line, the current transformer detects the fault current, and the protection device immediately issues a tripping signal. The operating mechanism receives the signal and rapidly drives the main contacts to separate. The vacuum arc quenching chamber instantly extinguishes the arc, cutting off the fault current and protecting the safety of the power system.

  • Reclosing Operation: After the fault current is interrupted, the recloser automatically performs a reclosing operation after a preset time interval. The operating mechanism re-closes the main contacts to restore power to the line. If the fault still exists, the recloser will detect the fault current again and trip. It will then perform multiple reclosing attempts based on the set number of reclosures and time intervals until the fault is cleared or the maximum number of reclosures is reached.
