AC load bank 3KW-5MW

discuss personally

Model

Basic info Product Detail Supplier

Basic info

Brand	Wone
Model NO.	AC load bank 3KW-5MW
Power	5KW
Series	DRLB

Product Detail

Description

It is used for the detection and maintenance of AC power supply equipment, performance testing of various switches and contactors, loading,
burn-in, simulated load test, etc.
Power Range: 1kW-5MW (others on request).
Current Range: 0.1A-15000A.
Working Voltage Range: single phase, 3 phases, or custom requests.
Multiple safety protection functions : short circuit, over-current, over voltage, over-load, over temperature, fan fault, audible and visual alarm
device, etc.
It can be designed with RS232 and RS485 to connect with PC for remotecontrol.
Forced air cooling and water cooled are available.
Production Time :3-4 weeks
Widely used in test equipment, such as generator load, charging pile test,inverter power supply, data center test, server room load test, UPS, etc.

Parameter

Dimensions (mm)
Power	L±5	W±5	H±5	h±5
3KW	580	380	250	70
5KW	680	380	250	70
6KW	680	450	250	70
8KW	450	500	700	70
10KW	500	500	800	100
15KW	500	550	800	100
20KW	600	600	800	100
25KW	600	650	800	100
30KW	600	650	1000	100
40KW	680	680	1100	100
50KW	680	680	1200	100
60KW	850	850	1200	100
80KW	850	850	1300	150
100KW	850	850	1400	150
120KW	900	850	1400	150
150KW	900	850	1500	150
200KW	1000	850	1500	150
300KW	1400	1200	1650	150
400KW	1500	1200	1800	150
500KW	1500	1400	1800	150
600KW	1500	1500	1800	150
800KW	1800	1500	1900	150
1000KW	2000	1500	1900	150
1200KW	2000	1600	1900	150
1500KW	2200	1600	1900	150
2000KW	2400	1800	2000	150
