| Brand | POWERTECH |
| Model NO. | Single-phase Multi-tariff Energy Meter |
| Rated normal current | 100A |
| Analogue input type | External CT |
| Communication port support | RS485/RF |
| Number of outputs | 1 pulse |
| Number of inputs | 1 |
| Multi-tarff | 4 tariffs |
| Current transformer | Yes |
| Series | GSD7666-CTF |
Description
GSD7666-CTF is a CT-connection single-phase energy meter with an embedded RF module for local meter reading.The meter is used to accurately measure energy for commercial & industrial customers. Through RF communication & Handheld Units(HHUs).
Feature
Multi-tariff.
Screw sealing.
Real-time clock.
Push button .
Replaceable battery.
Detection & prevention of tampering.
Active energy measurement .
Import & export energy measurement .
Neutral current measurement .
Infrared port/RS485/RF(optional) .
Programmable auto-scroll display .
LCD display capable of reading without power.
Specifications
| Main |
|
|---|---|
| Range | GSD |
| Model NO. | GSD7666-CTF |
| Product or Componet Type | Energy meters |
| Country of origin | China |
| Complementary |
|
|---|---|
| Phase | Single-phase |
| Type of measurement | Active power;current voltage;Active power |
| Metering type | Active, reactive, apparent energy (signed, four quadrant) |
| Device Application | Multi-tariff |
| Accuracy class | Class1.0 active energy IEC 62053-22 |
| Input type | CT |
| Rated voltage | 230V |
| Network Frequency | 50~60Hz |
| Technology Type | Electronic |
| Display Type | LCD display |
| Sampling rate | --- |
| Maximum value measured | <2W<8VA-----1 |
| Tariff input | Tariff 4) |
| Communication port protocol | --- |
| Communication port support | --- |
| Local signalling | Green indicator light power ON Yellow flashing LED accuracy checking alarm overload |
| Number of inputs | --- |
| Number of Outputs | --- |
| Output voltage | --- |
| Mounting Mode | --- |
| Mounting Support | --- |
| Connections - terminals | Maximum cable size 8mm |
| Standards | IEC62053-21 |
| Environment |
|
|---|---|
| IP degree of protection | P54 |
| Ambient air temperature for operation | -25℃~+70℃- IEC |
| Ambient Air Temperature for Storage | -40℃~+85℃ |
| Dimensions | 111*147.5*52.7 |
| Packing Units |
|
|---|---|
| Unit Type of Package 1 | PCE |
| Package 1 Height | |
| Package 1 Width | |
| Package 1 Length | |
| Package 1 Weight | |
Dimensions
