Switchgear Insulating Bushing

switchgear insulating bushings, crafted via APG technique, provide reliable insulation for12kV, 24kv, and 40.5kV equipment. The epoxy resin bushings facilitate insulation, isolation, andconnection transitions within complete switchgear sets. Resistant to dirt and moisture, the epoxyresin cast bushing of switchgear require minimal maintenance, needing only periodic surface
cleaning. Installation is straightforward, with busbars passing directly through the bushing'scentral hole. These robust switchgear insulation bushings ensure safe and effcient electricalconnections.  Suitable for various types of metal enclosed switchgear, ring main unit, and high-voltage cabinet in box type substations. The specific cabinet bodies and models are as follows: indoor fixed ring main unit HXGN17-12, indoor metal armored movable switchgear KYN28-12, indoor inflatable ring main unit HXGN15-24, indoor fixed high-voltage switchgear XGN66-40.5, etc
