| Brand | HK Electrical |
| Model NO. | FJ-IL-G06 Series High Bay Light |
| Ingress Protection | IP65 |
| Rated power | 240W |
| Wide voltage input range | AC 100-265V |
| Lumen efficiency | 130lm/W |
| CCT(color temperature) | 3000-6000K |
| CRI(color render index) | ≥80 |
| beam angle | 60°/90° |
| PF(Power Factor) | ≥0.95 |
| Series | FJ-IL-G06 Series |
Overview
FJ-IL-G06 uses SMD3030 chips to provide excellent lumen output, long-lasting stability and outstanding visual effects
High-end LED driver, this UFO series LED industrial light has a long service life and 5 years warranty.
Unique heat dissipation design, stable product performance.
Excellent heat dissipation function, so that the led always work in a cool environment, significantly improve the life and efficacy.
0-10V, DALI, time-controlled dimming suitable for different project needs.
technical parameters
Model |
Power |
Lumen efficiency |
CCT |
CRI |
Input voltage |
IP |
Beam angel |
PF |
Dimension |
FJ-IL-G06-100W |
100W |
130lm/w |
3000-6000K |
>80 |
AC100-265V |
IP65 |
60°/90° |
≥0.95 |
φ380xH153 |
FJ-IL-G06-120W |
120W |
130lm/w |
3000-6000K |
>80 |
AC100-265V |
IP65 |
60°/90° |
≥0.95 |
φ380xH153 |
FJ-IL-G06-150W |
150W |
130lm/w |
3000-6000K |
>80 |
AC100-265V |
IP65 |
60°/90° |
≥0.95 |
φ420xH153 |
FJ-IL-G06-240W |
200W |
130lm/w |
3000-6000K |
>80 |
AC100-265V |
IP65 |
60°/90° |
≥0.95 |
φ155xH158 |
FJ-IL-G06-240W |
240W |
130lm/w |
3000-6000K |
>80 |
AC100-265V |
IP65 |
60°/90° |
≥0.95 |
φ455xH158 |
