| Brand | HK Electrical |
| Model NO. | FJ-IL-Mercury Series High Bay Light |
| Rated power | 240W |
| Wide voltage input range | AC 100-265V |
| Lumen efficiency | 130~210lm/W |
| CCT(color temperature) | 3000-6000K |
| CRI(color render index) | ≥80 |
| beam angle | 60°/90° |
| PF(Power Factor) | ≥0.95 |
| Series | FJ-IL-Mercury Series |
Overview
Adopting high brightness 2835 chip, the actual luminous efficacy of the whole lamp ≥180lm/w;
Dodecagonal design, more beautiful and elegant appearance;
Built-in microwave and PIR sensing to meet different customer needs, secondary energy saving;
Equipped with emergency power supply, emergency power 10-15W, emergency time 1.5 hours;
Color temperature adjustable (3CCT) & power adjustable (60/80/100%), greatly reduce the inventory pressure 0-10v, Dali dimming to meet different project needs.
technical parameters
Model |
Power |
Lumen efficiency |
CCT |
CRI |
Input voltage |
IP |
Beam angel |
PF |
Dimension |
FJ-IL-ME-100W |
100W |
130~210lm/w |
3000-6000K |
>80 |
AC100-265V |
IP65 |
60°/90° |
≥0.95 |
φ240xH155 |
FJ-IL-ME-150W |
150W |
130~210lm/w |
3000-6000K |
>80 |
AC100-265V |
IP65 |
60°/90° |
≥0.95 |
φ280xH155 |
FJ-IL-ME-200W |
200W |
130~210lm/w |
3000-6000K |
>80 |
AC100-265V |
IP65 |
60°/90° |
≥0.95 |
φ320xH155 |
FJ-IL-ME-240W |
240W |
130~210lm/w |
3000-6000K |
>80 |
AC100-265V |
IP65 |
60°/90° |
≥0.95 |
φ320xH155 |
