22kV 24kV 30kV 33kV Solid Insulated Switchgear/switchboard panel

Description

Pioneer in China's eco-friendly switchgear sector, we have specialized in R&D and manufacturing of SF₆-free switchgear for decades. With core technologies, we have established industry standards. Boasting a fully independent end-to-end production chain, we have built a product matrix of zero-emission and high-reliability eco-friendly switchgear, making us a trusted choice for power grid construction.

This product is a new generation of small power distribution equipment. It is an expandable SF6 insulated switchgear. It can provide 10 different configurations, suitable for most applications in 12/24/36 kV distribution network, they represent a complete solution for 12/24/36 kV secondary distribution network.

The voltage classes of some of these eco-friendly switchgears include 6kV, 6.3kV, 6.6kV, 6.9kV, 7.2kV, 10kV, 10.5kV, 11kV, 11.5kV, 12kV, 13.2kV, 13.8kV, 14.5kV, 14.4kV, 15kV, 15.5kV, 15.6kV, 17.5kV, 20kV, 21.9kV, 22kV, 24kV, 30kV, 33kV, 33.5kV, 34.5kV, 35kV, 36kV, 38kV, 38.5kV, 40.5kV, 44kV, 45kV, 46kV, 66kV and 69kV. and customization is available.

Feature

• Vacuum load switch and related operating mechanism are maintenance-free;

• The mechanical interlock is simple and reliable, prevents misoperation, and is easy to operate;

• The functional units are separated from each other and equipped with reliable pressure relief channels, which can effectively prevent the expansion of faults;

• The observation hole can conveniently observe the insulation break and the connection of the cable terminal;

• The secondary computer room has enough space, convenient wiring, and enough space in the cable room, suitable for ordinary cable connection;

• The fuse is easy to replace;

Use environment

• Maximum temperature: +50℃; Minimum temperature: -40℃

• Humidity: no more than 95% per day, no more than 90% per month

• Earthquake intensity: 8

• Altitude: ≤5000 meters
