SSCB Series Solid-State Circuit-Breaker

discuss personally

Model

Basic info Product Detail Supplier

Basic info

Brand	ROCKWILL
Model NO.	SSCB Series Solid-State Circuit-Breaker
Rated voltage	DC 1.5kV
Rated normal current	1600A
Series	SSCB Series

Product Detail

Overview

Solid-State Circuit-Breaker for DC applications with unidirectional or bi-directional power flow such as batteries, electrolyzer and other DC loads.

Security at its Best

SSCB is designed to open high short circuit currents in a few microseconds through its high electrical features. SSCB is presented as a solution where fuses do not guarantee a proper protection selectivity or where the availability is critical.

The SSCB complies with the most demanding safety codes in the world adapting to the necessities of the market. SSCB is a solution designed and patented by Hitachi Energy and it uses an innovative solution to minimize the overvoltage in the fault opening. With an easy integration and low power consumption, these devices allow remote monitoring and control, as well as a high-performance protecting facility from short circuit events.

Main Characteristics
● DC storage solution as batteries: prevents battery racks fuses from blowing up. It keeps the complete system working after a fault.
● 1000x FASTER than conventional mechanical ACB, 100x FASTER than conventional fuses
● Increase the availability of renewable Energy Project + Battery Integration Solution
● Low conduction losses
● To protect up to 1500V DC systems
● Patented solution

Technology parameters
