36kV/40.5kV Prefabricated Substation
Key attributes
| Brand | ROCKWILL |
| Model NO. | 36kV/40.5kV Prefabricated Substation |
| Rated voltage | 40.5kV |
| Rated normal current | 1250A |
| Rated frequency | 50/60Hz |
| Series | YB |
Product descriptions from the supplier
36kV/40.5kV Prefabricated Substation Characteristics：
This type substations are the HV side 40.5 kV, LV side 0.4-12 kV and 3 phase outdoor completeequipment .It is wide used in cities , towns ,factories and oil fields, wharfs etc. It is also used insome construction sites. The characteristics are small volume, convenient installation, low cost,high automation safe and reliable operation. Substation is combined with HV switch room,LVswitch room, relay room and transformer room.
Main technical specifications for 36kV/40.5kV Prefabricated Substation：
Main Primacy Wiring Circuit Schemas for Substation(40.5kV)：
Wiring type A - 40.5kV
Wiring type B - 40.5kV
Wiring type C - 40.5kV
Wiring type D - 40.5kV
