10-30kW Three-phase OFF-Grid Wind&Solar Hybrid Controller

Name: 10-30kW Three-phase OFF-Grid Wind&Solar Hybrid Controller
Brand: Yueqing HK Electrical Trading Co., Ltd.
SKU: 2531
Price: 1.99 USD
Availability: InStock

Yueqing HK Electrical Trading Co., Ltd.

9yrs 100+ staff 1000+m² US$300000000+ China

Attributes Description Documentation Resource Library Supplier

Key attributes

Brand	HK Electrical
Model NO.	10-30kW Three-phase OFF-Grid Wind&Solar Hybrid Controller
Rated Output Rating	30KW
Input Voltage	DC240V
Series	WIT

Description

Features

Can be applied in wind, solar, wind&solar hybrid power generation system
Simple structure, complete function
Lowno-load loss byusing industrial frequency transformer
R5232/R5485/GPRS optional (Those with GPR5 can also be monitored through App.
CE certification

Applications

Application in wind, Solar, Wind&Solar hybrid power generation station.
Application in household wind&solar hybrid power generation system.
Power supply for those unmanned regions like the coastal islands, remote mountainous regions and border posts.

Technology Parameters

Model	WIT100-120	WIT100-240	WIT200-240	WIT300-240
DC Input Parameters
Rated battery voltage	120VDC	240VDC	240VDC	240VDC
Input overvoltage point	170VDC	340VDC	340VDC	340VDC
Input overvoltage recovery point	165VDC	330VDC	330VDC	330VDC
Input undervoltage point	108VDC	216VDC	216VDC	216VDC
Input undervoltage recovery point	120VDC	240VDC	240VDC	240VDC
AC Output Parameters
Output phase number	Three-Phase
Rated output power	10kW	10kW	20kW	30kW
Rated output voltage	380VAC
Rated output frequency	50/60±0.5Hz
THDi	<5%
Efficiency
Max. conversion efficiency	≥90%
Protection Functions
DC input overvoltage/undervoltage protection	YES
DC reversed connection protection	YES
AC output overload protection	YES
AC short circuit protection	YES
Surge protection	YES
Over-temperature protection	YES
General Parameters
Display mode	LCD
Isolation mode	Industrial frequency isolation
No-load current	≤2A	≤1.25A	≤2A	≤2.5A
Ambient temperature	-20℃ ~ +40℃
Humidity	5%~95%, No condensing
Noise	<60dB
Cooling mode	Forced air cooling
Cover protection class	IP20
Product dimension (WHD)	500x710x500mm		600x1180x600mm
Product net weight	100kg		200kg	280kg
Note: Part of parameters can be adjusted according to customer's specific demand.
