| Brand | ROCKWILL |
| Series | RCW |
| Rated voltage | 22kV |
| Rated current | 630/1250/1600A |
| Rated short circuit breaking current | 20/25/31.5kA |
| Rated frequency | 50/60Hz |
Our ROCKWILL 22kV pole-mounted automatic circuit recloser is an integrated overhead power protection solution, composed of a vacuum circuit breaker for circuit interruption, an intelligent electronic controller for overcurrent detection and recloser actuation, and a matched interconnection control cable. This Smart Recloser design supports reliable switching and protection for overhead distribution lines.
It supports single-pole or double-pole installation, and can be mounted on pole tops for overhead line switching or installed on frames inside substations for flexible application. Committed to continuous technological innovation and standardized management, we provide reliable 22kV reclosers for global power distribution projects. Our role as an Outdoor Recloser Supplier covers both standard and customized production.
Key Features
| Item | Unit | Value |
|---|---|---|
| Rated voltage | kV | 22 |
| Rated frequency | Hz | 50/60 |
| Rated current | A | 630/1250/1600 |
| Rated short‑circuit breaking current | kA | 20/25/31.5 |
| Rated peak withstand current | kA | 50/63/80 |
| Rated short‑time withstand current | kA/4s | 25 |
| Rated short‑circuit making current (peak) | kA | 50/63/80 |
| Mechanical endurance | Times | 10000 |
| Rated short‑circuit current breaking times | Times | 20 |
| 1‑min power frequency withstand voltage of the main circuit | kV | 50/60/65 |
| Lightning impulse withstand voltage | kV | 95/125 |
Npte：The 22kV pole mounted recloser can be supplied with different rated currents, short-circuit breaking currents, and protection schemes. It supports single-pole or double-pole installation and can be mounted on pole tops or substation frames.
Our Pole Mounted Recloser/Reclosure China Manufacturer capabilities cover both standard and customized production. Typical applications include rural distribution networks, urban feeders, and outdoor pole-mounted power supply systems. Please confirm the required parameters before ordering.
| Ambient air temperature — upper limit | +40 °C |
| Ambient air temperature — 24 h average | +35 °C |
| Ambient air temperature — lower limit | –25 °C |
| Altitude above sea level | ≤ 1 000 m |
| Relative humidity — 24 h average | ≤ 95% (at +40 °C) |
| Relative humidity — monthly average | ≤ 90% |
| Water vapour pressure — 24 h average | ≤ 2.2 kPa |
| Water vapour pressure — monthly average | ≤ 1.8 kPa |
| Solar radiation | ≤ 1 000 W/m² |
| Wind speed (outdoor) | ≤ 34 m/s (mild) |
| Pollution degree | Class III |
This outdoor vacuum Auto Circuit recloser features an intelligent automatic reclosing function that performs multiple cycles to clear transient faults. By automatically restoring power after temporary issues, it significantly reduces outage durations and minimizes the need for manual intervention by utility teams.
Yes. Rockwill provides a comprehensive OEM/ODM program for the RCW vacuum recloser. However, we are very selective in our partner selection — we specifically seek manufacturers and local partners with strong technical capabilities, solid engineering background, and local service capacity. Our goal is to partner with entities that can not only distribute but also provide local technical support to promote our advanced technology.
Two types: magnetic actuator (M/G, mechanical life 30000 times) and spring mechanism (N, mechanical life 10000 times). Magnetic type can add manual closing function with code “C”.
It integrates control, overcurrent protection, measurement, communication, fault detection and online opening‑closing monitoring, matched with dedicated recloser controller.
Yes. As a leading source manufacturer, we provide full-chain R&D and production for the outdoor vacuum Auto Circuit recloser. We can customize parameters—including specific voltage ratings like 21.9kV or 25.8kV, communication protocols, and protection logic—to ensure the equipment matches your regional grid standards and project needs.
The Rockwill standard smart recloser offers high precision with a wide measuring range (2A–16,000A). Simply ensure your normal current is within this standard range when making a selection.
Yes. In addition to the standard 2A–16,000A range, Rockwill provides custom-configured units for ultra-low current measurement and protection in the 0.1A–2A range.
