High voltage current limiting fuse for full range protection

Name: High voltage current limiting fuse for full range protection
Brand: Zhejiang Xinyouxiang Electric Technology Co., Ltd.
SKU: 1626
Availability: InStock

Zhejiang Xinyouxiang Electric Technology Co., Ltd.

2yrs 100+ staff 1000+m² US$300000000+ China

Attributes Description Documentation Resource Library Supplier

Key attributes

Brand	Xinyouxiang
Model NO.	High voltage current limiting fuse for full range protection
Rated voltage	12kV
Rated normal current	63A
Rated short circuit breaking current	50kA
Series	XRNT1-12

Description

This product is suitable for indoor AC 50Hz, rated voltage 12Kv system. It can reliably cut off any fault current between the minimum breaking current and the rated breaking current. The product not only has the high breaking capacity of current limiting fuses, but also has the good small current protection characteristics of non current limiting fuses, which can achieve good protection characteristics for full range breaking. High voltage current limiting fuse for full range protection
