GQ30-L Series Metal Push Button Switch

Name: GQ30-L Series Metal Push Button Switch
Brand: Yueqing HK Electrical Trading Co., Ltd.
SKU: 1375
Price: 16.00 USD
Availability: InStock

Yueqing HK Electrical Trading Co., Ltd.

9yrs 100+ staff 1000+m² US$300000000+ China

Attributes Description Documentation Resource Library Supplier

Key attributes

Brand	HK Electrical
Model NO.	GQ30-L Series Metal Push Button Switch
operation mode	mechanical self-latching
cabinet type	stainless steel
installation diameter	30mm
button Head shape	flat round
interface configure	1*C+NO+NC
Certification	CE+CCC
switch rating	250Ui 20A
Mechanical life	≥1000000 cycle
Electrical life	≥50000 cycle
Dielectric strength	1500VAC
Contact resistance	≤50mΩ
Insulation resistance	≥100MΩ(500VDC)
Operating environment	-25 ℃~55℃
Operation pressure	4N
Operation travel	2.5mm
Terminal type	PIN type
LED color	red/green/blue/yellow/white
LED rated voltage	6V/12V/24V
lamp type	lighting ring+power button
Series	GQ30-L Series

Description

☆Panel Cutout Dimension φ30，Ui:250V,Ith:20A
☆Unique switch structure supports 20A overload current, wider application
☆Bigger buttons for more functions, eye-catching appearance and simple triggering
☆Latching type for gear self-locking structure to improve stability
☆IP65(IP67 made to order ) ,IK09
☆Certificate: CCC/CE

For more information, please read the selection manual. ↓↓↓

Documentation Resource Library

Restricted

GQ22/25/30-L Series metal push button switch selection manual GQ22/25/30-L Series metal push button switch selection manual
