| Brand | Xinyouxiang |
| Model NO. | Compact High-Voltage Load Switch |
| Rated voltage | 24kV |
| Series | XK4-12/17.5/24kV |
The XK4 compact high-voltage load switch is a universal load switch used for indoor equipment. The product complies with DINVDE0670-301, VDE0670-303, and IEC60265-1
This switch is suitable for the following situations
Load and no-load transformers, capacitor banks, power lines, overhead cables, ring networks for both no-load and load.
When the switch is opened, the XK4 load switch has a clear visible insulation fracture, which meets the VDE0670-2 standard.
The switch contacts and operating mechanism have undergone the most compact design, enabling the product to have fast breaking speed and high-strength short-circuit closing ability. Under any short-circuit current within the performance range of the switch, the switch or other The equipment will not be damaged.
Suitable for mainstream cabinets such as indoor air insulated ring main unit (HXGN17-12), indoor metal armored withdrawable switchgear (KYN28-12), indoor metal armored withdrawable switchgear (KYN28-17.5/24), indoor SF6 gas insulated ring main unit (HXGN-24), etc. with corresponding voltage levels
