4 Pole Fuse holder RT18 Series AC and DC Din Rail Fuse Holder
Key attributes
| Brand | Switchgear parts |
| Model NO. | 4 Pole Fuse holder RT18 Series AC and DC Din Rail Fuse Holder |
| number of poles | 4p |
| Series | RT18 |
Product descriptions from the supplier
Din Rail Fuse Holder can be applied in both AC and DC area.It is suitable for AC 50HZ/60HZ, rated insulation voltage up to 800V, Din Rail fuse holder can withstand the conventional thermal current and the expected short-circuit impulse current to 100kA. Din Rail fuse holder comply with the national standard GB/T13539.2 and the International Electrotechnical Commission standard IEC60269-2.
| Product Item | RT18 |
| Rated Current | 32A, 63A, 125A |
| Rated voltage | 400V/690V |
| Breaking Capacity（kA） | 100kA(500VAC)/50kA(690VAC) |
| Utilization Category | AC-22B |
| Standard | IEC 60269-2 GB/T 13539.2 |
| Applications | Power control system
industry electrical equipment |
