| Brand | Rw Energy |
| Model NO. | 1MW/2.08 MWh Liquid-cooling container |
| Rated voltage | 1331.2V |
| Battery Capacity | 2MWh |
| Series | REL2000 |
1MW/2.08 MWh Liquid-cooling container
◼ High Density: A single container can store up to 2.08 MWh of energy, saving space.
◼ High Safety: Three-tier fire protection at the PACK, cluster, and cabin levels ensures safe system operation.
◼ High Efficiency: Intelligent cooling design ensures reliable energy conversion.
| Liquid-cooling container |
REL2000 |
| Battery type(Ah) |
LFP-314 |
| System configuration |
1P416S*5 |
| Rated voltage(V) |
1331.2 |
| Dimensions L*W*H(mm) |
6058 * 2438 * 2896 |
| Rated energy(MWh) |
2.08 |
| Weight(t) |
~35 |
| IP level |
IP54 |
| Corrosion resistance |
cs |
Adopting an intelligent liquid cooling system, the temperature difference between battery cells is ≤ 2.5 ℃, significantly better than the air cooling system, effectively suppressing battery aging and extending cycle life by more than 20%.
The whole machine has IP54 protection and CS anti-corrosion level, and can operate stably in an environment of -20 ℃ to 50 ℃. It is suitable for harsh scenarios such as outdoor substations and industrial parks.
Equipped with a three-level fire protection system - electric core level thermal runaway warning, PACK level aerosol fire extinguishing, cabin level water sprinkler+explosion venting design, achieving full chain fire protection from local to overall.
