Four Major Causes and Solutions for Transformer Voltage Imbalance

Transformers play an indispensable role in power systems, and almost every electrical device relies on their stable power supply. Sometimes you may find that the transformer's voltage is unstable, or even unbalanced. This phenomenon not only affects the operating efficiency of equipment but also may bring a series of serious safety hazards. What exactly causes transformer voltage imbalance? And how to effectively solve this problem?

1.Three-Phase Load Imbalance

The voltage balance of a transformer is closely related to load distribution. Three-phase load imbalance is often the primary factor leading to voltage imbalance. Simply put, unbalanced three-phase load is like a car with severely worn tires on one side and no problem on the other, causing the car to deviate. Under load imbalance, the current of some phases is too large, leading to an increase in the voltage of one phase of the transformer, while the voltage of other phases is relatively reduced, resulting in voltage imbalance.

Especially in industrial power consumption, the start-stop of equipment and irregular changes in operating status often lead to severe load imbalance. To solve this problem, on the one hand, it is necessary to reasonably distribute equipment loads to achieve load balance as much as possible; on the other hand, the transformer capacity also needs to be appropriately matched to the load demand to prevent load imbalance due to insufficient capacity. Automatic load distribution devices can be installed to adjust the load of each phase in real-time to maintain voltage stability.

2. Power Line Faults

Power line faults, especially phase-to-phase short circuits or ground faults, are also common causes of voltage imbalance. If one conductor of the power line has a problem, it will directly affect the working state of the transformer. A broken line or poor contact of one phase leads to abnormal current flow, resulting in a voltage drop or even complete failure of that phase. In contrast, the voltage of the other two phases may rise due to load redistribution, forming voltage imbalance.

 The solution to line faults is usually to quickly locate and repair the problem when a fault occurs. To avoid this situation, power companies need to regularly inspect and maintain lines, use high-quality and durable conductors to ensure long-term stable operation of lines. In some special cases, the adoption of automatic fault isolation technology can help quickly detect faults and cut off the problematic lines, thereby preventing the further expansion of voltage imbalance.

3.Transformer Internal Issues

Even if the lines and loads are normal, problems with the transformer itself may cause voltage imbalance. These problems may be due to transformer design defects, unqualified manufacturing quality, or equipment aging caused by long-term operation. Transformer winding damage, iron core defects, and poor cooling systems will all affect its normal operation. When a problem occurs in one phase of the transformer, the voltage distribution will be affected, and the problem of voltage imbalance will arise. To avoid this situation, transformers should be regularly maintained and inspected, especially effective testing and monitoring of their core components. If any abnormality is found in a part of the transformer, it should be shut down for inspection in a timely manner to avoid long-term operation in an unbalanced state, which may lead to more serious faults.

4. External Interference in Power Supply System

Power systems are usually large networks composed of multiple substations, lines, and equipment. In this complex system, external interference may also cause voltage imbalance. Frequent grid dispatching, improper power dispatching of adjacent substations, and even sudden increases in power consumption by large-scale remote power users will affect the stability of the entire power system. Grid voltage fluctuations, harmonic pollution, and even electromagnetic interference from power equipment may cause transformer voltage fluctuations and imbalance. To address this problem, power companies and relevant departments need to strengthen the coordinated management of grid operation, avoid frequent large-scale power dispatching, and minimize electromagnetic interference. Filters, voltage regulators, and other equipment can also be installed to reduce the impact of external interference on transformers, thereby ensuring the stable operation of transformer voltage.

• Reasonable Load Distribution: Ensure balanced load distribution, especially in industrial and commercial power consumption, and try to achieve balanced distribution of three-phase loads. Real-time monitoring and automatic load adjustment can effectively avoid voltage imbalance caused by uneven loads.

• Strengthen Line Inspection: Regularly inspect power lines to ensure they are intact. If a fault occurs, take corresponding repair measures promptly. Lines that are aging or have potential fault risks should be replaced or reinforced in advance.

• Maintain Equipment Health: Regularly inspect and maintain transformers, replace aging components in a timely manner, and ensure that equipment is always in good operating condition. Real-time track the operating status of transformers through online monitoring systems to provide early warning of potential problems.

• Improve Grid Management Level: Strengthen grid dispatching and management to avoid excessive load fluctuations or dispatch imbalances in the power system. Provide early warning and emergency response in advance for large-scale sudden increases or decreases in power consumption.

The problem of transformer voltage imbalance is not unsolvable. By starting from multiple aspects such as load distribution, power lines, equipment health, and external interference, and gradually optimizing and adjusting, the voltage stability of the transformer can be completely restored, ensuring the normal operation of the entire power system.
